Dimmer Actuator – 4 Fold

Dimming Actuator 4 Fold 4A – TADLD-04/03.1

MSRP
1499$

Description
Constant voltage drive mode, input 12-24V DC, rated current 4A, RGBW control. KNX functions including switching, relative & absolute dimming, status response, scene control (15 folds), preset, staircase lighting etc

Features

  • Switching
  • Relative and absolute dimming
  • Status report, error report
  • Scene and preset function
  • Staircase lighting function
  • Preset a Brightness value after bus voltage recovery
  • Constant voltage drive mode
  • Manual operation and status indication

Specifications

Bus voltage 21-30V DC, Via KNX bus
Bus current<12mA
Bus consumption<360mW
Un rated voltage110-250V AC (50/60Hz)
In rated current4A
Load capacity16A/200uF
Max.switching current4A/110/250V AC
Machanical endurance>100×10000
Electrical endurance>1×10000
ModelTADLD-04/03.1
